Low Noise Circular Vibrating Screen Machine For Clay Coal Or Chemicals
  • Low Noise Circular Vibrating Screen Machine For Clay Coal Or Chemicals
  • Low Noise Circular Vibrating Screen Machine For Clay Coal Or Chemicals
Low Noise Circular Vibrating Screen Machine For Clay Coal Or Chemicals

Low Noise Circular Vibrating Screen Machine For Clay Coal Or Chemicals

Place of Origin SICHUAN,CHINA
Brand Name XINGHE YONGCHEN
Certification ISO9001,ISO14001,ISO45001
Model Number YKR\CVB
Product Details
Product Name:
Circular Vibrating Screen
Application::
Construction, Metallurgy, Mining, Quarry, Ore Stone
Warranty:
1 Year
Customization::
Available
Factory Visit:
Welcomed Warmly
Video Outgoing-Inspection:
Provided
Machinery Test:
Provided
HS Code:
84742010
Highlight:

Circular Vibrating Screen Machine

,

Low Noise Vibrating Screen Machine

Payment & Shipping Terms
Minimum Order Quantity
1 Piece
Packaging Details
Wooden Box/ Container
Delivery Time
45-60D
Payment Terms
L/C,T/T,Western Union,MoneyGram
Supply Ability
500 Pieces Per Year
Product Description

Low Noise Circular Vibrating Screen – Handles Clay, Coal, or Chemicals

Overview
The YKR-H/SK Series Circular Vibrating Screen is widely used in various screening applications, including aggregates, metallurgy, metal mining, and coal processing.

  • YKR-H Series:

    • Max. feed size: ≤300mm

    • Grading range: 2–150mm

  • YKR-SK Series:

    • Max. feed size: ≤250mm

    • Grading range: 2–76mm

Product Features
The YKR series vibrating screen is developed with advanced design concepts. Through years of application experience in metal mining and aggregate industries, along with continuous improvements and standardization, it has evolved into a mature and reliable screening solution.

YKR Series Circular Vibrating Screen Specifications

Model Screen Width (mm) Screen Length (mm) Angle (°) Vibration Frequency (min⁻¹) Double Amplitude (mm) Power (kW) Weight (kg)
YKR1437H 1400 3750 18 (15–25) 800–900 7.0–10.0 11 3832
YKR1645H 1600 4500 18 (15–25) 800–900 7.0–10.0 15 5345
YKR1852H 1800 5250 18 (15–25) 800–900 7.0–10.0 18.5 6536
YKR2052H 2000 5250 18 (15–25) 800–900 7.0–10.0 22 7567
YKR2460H 2400 6000 18 (15–25) 800–900 7.0–10.0 30 10904
YKR3060H 3000 6000 20 (15–25) 800–900 6.0–9.0 30 13604
YKR3075H 3000 7200 20 (15–25) 800–900 6.0–9.0 45 14622
YKR3675H 3600 7200 20 (15–25) 800–900 6.0–9.0 2×30 24730
2YKR1437H 1400 3750 18 (15–25) 800–900 7.0–10.0 15 6076
2YKR1645H 1600 4500 18 (15–25) 800–900 7.0–10.0 22 8226
2YKR1852H 1800 5250 18 (15–25) 800–900 7.0–10.0 30 10990
2YKR2060H 2000 6000 18 (15–25) 800–900 7.0–10.0 30 12572
2YKR2460H 2400 6000 18 (15–25) 800–900 7.0–10.0 45 14740
2YKR3060H 3000 6000 20 (15–25) 800–900 6.0–9.0 45 18293
2YKR3075H 3000 7200 20 (15–25) 800–900 6.0–9.0 2×37 24230
2YKR3675H 3600 7200 20 (15–25) 800–900 6.0–9.0 2×45 32960
2YKR2460SK 2400 6000 18 (15–25) 800–900 7.0–10.0 37 11785
2YKR3060SK 3000 6000 20 (15–25) 800–900 6.0–9.0 45 14500
2YKR3075SK 3000 7200 20 (15–25) 800–900 6.0–9.0 2×37 19685
2YKR3675SK 3600 7200 20 (15–25) 800–900 6.0–9.0 2×45 30560
3YKR1852H 1800 5250 18 (15–25) 800–900 7.0–10.0 30 11528
3YKR2060H 2000 6000 18 (15–25) 800–900 7.0–10.0 37 13734
3YKR2460H 2400 6000 18 (15–25) 800–900 6.0–9.0 45 16526
3YKR3060H 3000 6000 20 (15–25) 800–900 6.0–9.0 45 17636
3YKR3075H 3000 7200 20 (15–25) 800–900 6.0–9.0 2×37 25210
3YKR3675H 3600 7200 20 (15–25) 800–900 6.0–9.0 2×45 32820



Accessories

Low Noise Circular Vibrating Screen Machine For Clay Coal Or Chemicals 0



Low Noise Circular Vibrating Screen Machine For Clay Coal Or Chemicals 1



Low Noise Circular Vibrating Screen Machine For Clay Coal Or Chemicals 2



Low Noise Circular Vibrating Screen Machine For Clay Coal Or Chemicals 3
